D-4 format example ----------------------------------------------------------


DS15 format example --------------------------------------------------------









DS15 format example --------------------------------------------------------


B100 format example ---------------------------------------------------------


R15 format example ----------------------------------------------------------







ANCORA (Flat wire)

Applications: hair brush, nail brush, technical brush industry,…

FINISHED: GALVANIZED

AVAILABLE: : It can be manufactured in any size and presentation required by the client. Most demanded sizes and formats.

SIZES AND FORMATS
Denomination
Available formats
Mmeters per kg. approx.
1,40 X 0,35 mm. Galvanized
DS15 D4
261,64
1,40 X 0,85 mm. Galvanized
DS15 D4
107,73
1,80 X 0,35 mm. Galvanized
DS15 D4
203,50
1,80 X 0,40 mm. Galvanized
DS15 D4
178,06
2,40 X 0,50 mm. Galvanized
DS15 D4
106,83
2,50 X 0,50 mm. Galvanized
DS15 D4
100,63





CIRCULAR CROSS-SECTION WIRE

Galvanized wire of circular cross-section, brush industry.

FINISHED: GALVANIZED

AVAILABLE: It can be manufactured in any size and presentation required by the client. Most demanded sizes and formats.

SIZES AND FORMATS
Denomination
Available formats
Mmeters per kg. approx.
Ø 0,50 mm. Galvanized DS15
652,94
Ø 0,60 mm. Galvanized DS15 B100
454,54
Ø 0,70 mm. Galvanized DS15 B100
333,33
Ø 0,80 mm. Galvanized DS15 B100
255,10
Ø 0,90 mm. Galvanized DS15 B100
201,61
Ø 1,00 mm. Galvanized DS15 B100
163,40
Ø 1,10 mm. Galvanizedo DS15 B100 R15
134,95
Ø 1,20 mm. Galvanized DS15 B100 R15
113,51
Ø 1,30 mm. Galvanized DS15 B100 R15
96,62
Ø 1,40 mm. Galvanized B100 R15
83,33
Ø 1,50 mm. Galvanized B100 R15
72,55
Ø 1,60 mm. Galvanized B100 R15
63,77
Ø 1,80 mm. Galvanized B100 R15
50,40
Ø 2,00 mm. Galvanized B100 R15
40,85
